Description
Specifications
- Sensitivity (1W, 1m, infinite baffle)SPL1W98.7dB
- Frequency response40 – 4000Hz
Thiele & Small parameters
- Resonance frequency (free air)fS39Hz
- Mechanical quality factorQMS5.10
- Electrical quality factorQES0.22
- Total quality factorQTS0.21
Large signal parameters
- Maximum linear excursion (one way)xmax7.5mm
- Maximum excursion before damagexlim52mm
- Air volume displaced at xmaxVD660cm³
- Power handlingP800W
- Program powerPmax1600W
Voice Coil
- Nominal impedanceZ8Ω
- DC resistanceRE5.1Ω
- Inductance (1kHz)LE0.8mH
- VC Diameter101.6mm
- Winding heightHVC20mm
Magnet
- Force factorBl23.8N/A
- Motor constantBl/√RE10.5N/√W
- Air gap heightHAG12mm
Diaphragm
- Effective diameter335mm
- Effective areaSD880cm²
- Moving mass (including air load)MMS98g
- Moving massMMD80g
Suspensions
- StiffnessKMS5.95N/mm
- ComplianceCMS168µm/N
- Equivalent volume to the complianceVAS184L
- Mechanical resistanceRMS4.7N·s/m
Dimensions
- Nominal diameter15″
- 380mm
- Overall diameter388mm
- Baffle cutout diameter352mm
- Overall depth161mm
- Volume occupied by the driver (estimated)3.3L
- Net weight6.0kg
