Description
Specifications
Nominal diameter: 300 mm (12 in)
Nominal impedance: 8 Ω
Minimum impedance: 5.7 Ω
Nominal power handling: 800 W
Continuous power handling: 1200 W
Sensitivity: 97.0 dB
Frequency range: 45 – 3200 Hz
Voice coil diameter: 100 mm (4.0 in)
Design (Enclosure Recommendations)
Recommended enclosure volume:
50.0 dm³
1.77 ft³
Recommended tuning frequency: 42 Hz
Parameters (Thiele & Small)
Resonance frequency (Fs): 47 Hz
DC resistance (Re): 4.7 Ω
Qes: 0.45
Qms: 5.5
Qts: 0.42
Equivalent compliance volume (Vas):
56.0 dm³
1.98 ft³
Effective cone area (Sd):
531.0 cm²
82.31 in²
Maximum linear excursion (Xmax): 8.0 mm
Moving mass (Mms): 82.0 g
BL factor: 17.0 T·m
Voice coil inductance (Le): 0.53 mH
EBP (Efficiency Bandwidth Product): 104 Hz
